(Alternative : Tenda TEF1106P-4-63W)

6-Port 10/100M PoE+ Switch
60 watts PoE power supply, up to 30 watts per port
4 10/100M PoE ports + 2 10/100M uplink ports
CCTV mode support remote PoE feeding up to 250m
LED for easy monitoring LNK/ACT/PoE status
IEEE 802.3at / IEEE 802.3af standard compliant
Plug&play, simple setup with no configuration needed

Specifications
Model FS1006PL
Power Power supply External Power Adaptor
Voltage Range DC48~57V
Switch Consumption <5W
Ethernet Speed 1~5 Port : 10/100Mbps, Uplink:100Mbps
Transmission Distanc
1-4port 100Meters with 100Mpbs
200Meters with 10Mbps
Uplink:100Meter with 100Mpbs
Network Switch Ethernet Standard IEEE 802.3/802.3u/802.3af/802.3at
Switching capacity 1.2G
Transfer Rate
14,880pps for 10Mbps
14,8800pps for 100Mbps
MAC Address 1K MAC address table
Function On — The vlan and 200meters is start to work
Link/ACT On Green The port is connecting
Blinks — The port is receiving or transmitting data
Off — The port is not linked successfully with the device
POE On Orange PD is connected
Off —

No PD is connected or power forw arding fails
Capacity 55W
Bandwidth PoE pin assignmnet V+(RJ45 Pin 1,2), V-(RJ45 Pin 3,6)
Environment Working Temperature 0~40?
Storage Temperature -40~70?
Humidity Non condesing 0~85%
Mechanical Dimension 102mm×75x22mm
Color Gray
